Economical Gauges

Economical Gauges

Product Details:

X

Product Description

Economical Gauges

These Economical Gauges are made of super quality materials. Economical Gauges are known with the best in performance as well as fine finishing and well in durability and most demanded in market. We provide various ranges of these Economical Gauges as per the requirements of the clients. These Gauges are reliable, durable and are known for wear & tear resistance. These gauges are widely used to measure the air, water, and gas pressure in various hydraulic and pneumatic applications.

Nominal Size (mm) 40, 50, 63, 80, 100, 150, 250
Scale Range 0.. Vacuum to 700 kg/cm2 & above on request
Accuracy in FSD 1.6%
Thread Connection 1/8", 1/4", 3/8", 1/2 " BSP & NPT, M-10, M-12, M-20
Mounting of Gauge Bottom, Surface, Back, Panel with 3 holes, Panel with bracket
Case and Bezel Drawn steel, SS 304
Pressure Elements Bourdon Tube
Diaphragm Nil
Wetted Parts Brass, SS 304
Application Chemical, Petrochemical, Plastic, Paper Pneumatic Control System and Air conditioning
Optional Liquid Filled
